Festool 578121 Domino DFC 500 Cordless Mortise and Tenon Joiner
Choose from the following recommended battery options in pull-down menu above:
- 4.0 Ah Starter Set (2x batteries & 1x TCL6 charger)
- 4.0 Ah Energy Set in Systainer (4x batteries & 1x TCL6 DUO charger)
- OR click to view all batteries options
Connect with precision, stability, and versatility: the cordless DOMINO.
Every wooden joint has its perks. The DOMINO jointing system, which includes a cordless joining machine and DOMINO dowels, brings them all together. The unique pendulum routing motion of the DOMINO creates precise, twist-proof elongated holes. The DOMINO dowel combines the strength of slotted and tenon joints with the flexibility of flat dowels. It's perfect for both delicate and sturdy pieces in the home and outdoors. Plus, the cordless version with its comfy spade handle gives you extra ease without any cables to worry about.
- Independent: 100% mobile with battery – whether you're in the workshop or on-site.
- Ergonomic: Work without fatigue thanks to the comfy handle.
- Precise: One-of-a-kind pendulum milling principle for accurate, effortless work.
- Quick and easy: Built-in stop pins for repeating dowel placement.
- Stable: Super stable and twist-proof joints thanks to the unique shape of the DOMINO dowel.
- Versatile: DOMINO tenons come in various sizes from 4x20 mm to 10x50 mm and in two types of wood for indoor and outdoor use.
- Sorted: The routing depths are just right for the dowel lengths and panel materials.
- Flexible: The DOMINO core connectors and furniture fittings let you create sturdy furniture setups that can be taken apart again.
- System: Accessories are a perfect fit for the whole DOMINO system.
Includes
- DOMINO Cutter D5
- Support Bracket
- Wrench
- All packed in SysGen3 M237 Systainer
Specifications
- Idle engine speed: 18,500 rpm
- Domino slot cutter diameter: 5 mm cutter included / 4, 6, 8, 10 mm cutters sold separately
- Miter routing: 0-90 degree
- Battery voltage: 18 V
- Routing depth stop: (12/15/20/25/28 mm)
- Routing height adjuster with scale: (5-30 mm)
- Dust extraction port diameter: 27 mm
- Weight: 7.5 lbs (3.4 kg)
Features & Benefits
Patented Routing Principle
The spiral cutter rotates and oscillates to create perfect mortises.
Mortise Width Adjustment
Adjusting the width of the mortise allows for easier alignment when joining panels.
Positioning
With an adjustable fence angle, retractable stop flaps, adjustable cutter height with step gauge, and precise mortise depth stop, the Domino joiner enables precise mortise placement and spacing.
Pivoting Fence
Fence creates angled mortises from 0-90 degrees with positive stops at 22.5, 45, & 67.5 degrees.
Depth Control
Quick, precise adjustment for five different mortising depths, relative to the size of the tenon required for the application.
Stepped Height Stop
Multiple step positions for different material thicknesses for fast and easy fence height adjustment.
Dust Extraction
Your mortises are clean and ready for glue when the Domino is used in combination with a dust extractor. Proper dust extraction greatly extends cutter life.
Carbide Tip Spiral Bit
Durable, long-lasting bit withstands 5,000-14,000 joints depending on material.
Rapid Bit Change
Means you can change a bit in under 30 seconds to match desired tenon size.
